Short Description:

Product type:2 layer FPC Flexible PCB
Applications:Automotive New Energy Battery
Line width and line spacing:0.1mm/0.1mm
Board thickness:0.3mm
Minimum Aperture:0.2mm
Copper Thickness:35um
Surface Treatment:ENIG 2-3uin
Special Process:Brown Oxide
Flame Retardant:94V0
Resistance welding color:Yellow
stiffness:Nickel sheet,FR4,Foam

Capel’s Service:
Support Custom 1-30 Layer FPC Flexible PCB,2-32 Layer Rigid-Flex Circuit Boards,1-60 Layer Rigid PCB,Reliable Quick Turn PCB Prototyping,Fast Turn SMT PCB Assembly

Industry We Service:
Medical Device, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…

How Capel's 2 Layer FPC Flexible PCB Automotive Boards New Energy Battery Flex Circuit Provides Reliability Solutions for Automotive New Energy Battery manufacturers
-Capel with 15 years of professional technical experience-
Launched the perfect solution for automotive new energy batteries - 2-layer FPC flexible PCB

Are you working in the automotive industry, with a particular focus on new energy battery technology? If so, we have the perfect product for you - 2-Layer FPC Flexible PCB. This innovative PCB is specifically designed for automotive new energy battery applications, providing unparalleled reliability, performance and flexibility.

When it comes to car batteries, precision is key. That's why our 2-layer FPC flexible PCBs are designed to meet the most demanding requirements. With line width and line spacing of 0.1mm/0.1mm, you can be confident in the accuracy and consistency of your electrical connections. This ensures optimal power transfer and maximum efficiency from the battery.

Additionally, a 0.3mm plate thickness enables a compact, lightweight battery design without compromising durability. The minimum aperture of 0.2mm ensures precise placement of components and enables seamless integration of various battery modules.
One of the key features of our 2-layer FPC flexible PCB is the copper thickness of 35um. This high copper thickness ensures excellent electrical conductivity, reducing energy loss and improving the overall performance of the battery. Additionally, our boards are ENIG 2-3uin surface treated for superior corrosion resistance and a smooth surface for reliable solder joints.

In order to further improve the reliability of 2-layer FPC flexible PCB, we use a special brown oxidation process. This process creates a protective layer on the surface of the circuit board, increasing its resistance to harsh environmental conditions such as temperature fluctuations, humidity and chemical exposure. Rest assured, your car battery will perform flawlessly no matter what conditions it encounters.

Safety is always a top priority, especially in the automotive industry. Our 2-layer FPC flexible PCBs are designed with flame retardancy in mind and comply with strict 94V0 industry standards. This ensures that the circuit board will not fuel or spread a fire, minimizing potential hazards and ensuring maximum safety for new energy batteries.

In terms of aesthetics, our 2-layer FPC flexible PCB uses resistance welding and comes in a bright yellow color. This eye-catching feature allows for easy identification and differentiation during production and assembly processes, streamlining your operations and increasing efficiency.

Flexibility is another outstanding feature of our 2-layer FPC flexible PCBs. With hardness options such as nickel sheet, FR4 and foam, you can customize your PCB to meet specific design requirements. Whether you need flexibility to fit into tight spaces or rigidity for added stability, we have a solution for you.

To sum up, our 2-layer FPC flexible PCB is the best choice for automotive new energy batteries. With their exceptional precision, reliability and flexibility, they are guaranteed to improve battery performance and safety. Believe in our superior products and use our expertise to stay ahead in the highly competitive automotive market. Choose our 2-layer FPC flexible PCBs and witness the changes they bring to your battery technology.

Capel Flexible PCB & Rigid-Flex PCB Process  Capability
Category Process Capability Category Process Capability
Production Type Single layer FPC / Double layers FPC
Multi-layer FPC / Aluminum PCBs
Rigid-Flex PCB
Layers Number 1-30 layers FPC
2-32 layers Rigid-FlexPCB
1-60 layers Rigid PCB
HDI Boards
Max Manufacture Size Single layer FPC 4000mm
Double layers FPC 1200mm
Multi-layers FPC 750mm
Rigid-Flex PCB 750mm
Insulating Layer
Thickness
27.5um /37.5/ 50um /65/ 75um / 100um /
125um / 150um
Board Thickness FPC 0.06mm - 0.4mm
Rigid-Flex PCB 0.25 - 6.0mm
Tolerance of PTH
Size
±0.075mm
Surface Finish Immersion Gold/Immersion
Silver/Gold Plating/Tin Plating/OSP
Stiffener FR4 / PI / PET / SUS / PSA/Alu
Semicircle Orifice Size Min 0.4mm Min Line Space/ width 0.045mm/0.045mm
Thickness Tolerance ±0.03mm Impedance 50Ω-120Ω
Copper Foil Thickness 9um/12um / 18um / 35um / 70um/100um Impedance
Controlled
Tolerance
±10%
Tolerance of NPTH
Size
±0.05mm The Min Flush Width 0.80mm
Min Via Hole 0.1mm Implement
Standard
GB / IPC-650 / IPC-6012 / IPC-6013II /
IPC-6013III
Capel manufactures customized high-precision Rigid Flexible Circuit Board / Flexible PCB / HDI PCB with 15 years of experience with our professionalism
2 Layer Flexible PCB Boards Stackup
4 Layer Rigid-Flex PCB Stackup
8 layer HDI PCBs
Testing And Inspection Equipment
Microscope Testing
AOI Inspection
2D Testing
Impedance Testing
RoHS Testing
Flying Probe
Horizontal Tester
Bending Teste
Capel provide customers customized PCB Service with 15 years of experience
Owning 3 factories for Flexible PCB&Rigid-Flex PCB, Rigid PCB, DIP/SMT Assembly;
300+Engineers Provide technical support for Pre-sales and after-sales online;
1-30 layers FPC, 2-32 layers Rigid-FlexPCB, 1-60 layers Rigid PCB
HDI Boards, Flexible PCB (FPC), Rigid-Flex PCBs, Multilayer PCBs, Single-sided PCB, Double-Sided Circuit Boards, Hollow Boards, Rogers PCB, rf PCB, Metal Core PCB, Special Process Boards, Ceramic PCB, Aluminum PCB, SMT & PTH Assembly, PCB Prototype Service.
Provide 24-hour PCB Prototyping service,Small Batches of circuit boards will be delivered in 5-7 days, Mass Production of PCB boards will be delivered in 2-3 weeks;
Industries we service: Medical Devices, IOT, TUT, UAV, Aviation, Automotive, Telecommunications, Consumer Electronics, Military, Aerospace, Industrial Control, Artificial Intelligence, EV, etc…
Our Production Capacity:
FPC and Rigid-Flex PCBs production capacity can reach more than 150000sqm per month,
PCB production capacity can reach 80000sqm per month,
PCB Assembling capacity at 150,000,000 components per month.
Our teams of engineers and researchers are dedicated to fulfilling your requirements with precision and professionalism.
